Station Automation System
Solution for switchgear automation

Station Automation from One Source

VIVAVIS SAS offers a wide range of data transmission protocols – from telecontrol protocols and field bus protocols through to proprietary protocol, which makes it universally applicable. Communication takes place via secure connections using certificate-based authentication or pre-shared keys. In cooperation with our subsidiary, AMW GmbH, we offer you the whole range of products and services for station automation: from individual components to complete turnkey systems.. Our portfolio of services includes the preparation of concepts, planning, installation and commissioning, as well as testing and documentation of measures.

Request now

Functions and features

Modular System Design
Based on the modular ACOS 750 with multi-processor capability, it is possible to set up highly flexible SAS systems for low-, medium-, high- and ultra-high voltage systems.
Control Flexibility
The user-friendly ACOS OP07A control, operation and monitoring device enables the operation and control of switching devices (local control stations), as well as the local visualisation of process and system information.
Visualisation of Local Control Stations
Local control is facilitated by an optimised version of the HIGH-LEIT ADMS system. Visualisation, control and monitoring of installations is freely configurable via Windows and can therefore easily be adapted to the customer’s operating concept.
Your Reliable Partner (Services)
The ACOS 300 series of protection devices offers reliable power grid protection for medium- and high-voltage grids and installations, including their operation and monitoring.
IT-Security
Our SAS devices feature a multi-level security concept, thereby fulfilling the requirements of the BDEW white paper on secure control and telecommunication systems. Thus, access to all components (bay controllers, gateways, station control terminal, ACOS ET projects and Switch) is possible only by means of a secure password with a high security level.
Modern Engineering Tool
Nowadays, there are various requirements on modern engineering tools – uniform engineering, diagnostic facilities and data security, to name but a few. ACOS ET fully complies with these requirements. Depending on the structure of an organisation, it is possible to implement both decentralised single workstations and central server solutions.
Diagnostics and Operation
ACOS ET is used for RTU diagnoses, whereas protection and control devices are diagnosed via EuroCAP or the integrated web server. The web server also includes different user roles and rights.
Your Reliable Partner (Services)
We support and advise you before the start of the project, create system concepts based on the customer's structure, deliver systems and carry out commissioning of complete systems as well as individual devices. Final testing work, such as bit tests or protection tests, including documentation, is also part of our scope of services.

Your benefits for switchgear automation

Everything from One Source

Everything from One Source

From project planning and engineering to installation and commissioning through to tests and the documentation - our portfolio covers all the necessary services for a successful project.
Long-Standing Expertise

Long-Standing Expertise

Extensive know-how in the field of switchgear automation
System Concept

System Concept

Coordinated systems on all levels (bay and station control level).
Modular Concept

Modular Concept

Our solutions are flexible, adaptable and economical thanks to the modular system design.
Suitable for All Voltage Levels

Suitable for All Voltage Levels

Our systems are ideally suited for high-, medium and low-voltage installations.
Versatile Communication

Versatile Communication

Communication takes place via a wide range of communication protocols: IEC 60870-101/103 (FW), IEC 60870-5-104 (ring, RSTP, MRP, etc.), IEC 61850 (ring, PRP etc.), Modbus RTU/TCP, PROFIBUS DP, DNP3.0, 3964R/RK512, SPA-Bus and TG80x
Investment Security thanks to Long-Term Compatibility

Investment Security thanks to Long-Term Compatibility

VIVAVIS SAS ensures the economical and future-proof implementation of your projects, fulfilling the highest technical demands and protecting your investments.
